Introduction
This flagship 4K USB camera is powered by the Sony IMX678 1/1.8" ultra-large format CMOS image sensor, delivering a stunning 8MP resolution (3840×2160). It features a 95° optimal Field of View (FOV) and supports high-speed capture up to 60FPS at 1080P and lower resolutions for silky-smooth video performance.
Ultra-Large Sensor & Exceptional Low-Light Performance
The 1/1.8-inch CMOS IMX678 sensor with 2.0μm pixel size empowers this USB camera with high dynamic range (HDR) and superior color accuracy. This 4K camera delivers clear, detailed images even in challenging lighting conditions, making it ideal for indoor and outdoor surveillance and AI vision applications.
Optimal Wide-Angle Coverage Without Distortion
Featuring a 95° diagonal FOV (90° horizontal, 58° vertical) with a 650nm IR lens (EFL: 4mm, F/no: 2.8), this USB UVC camera captures expansive scenes while maintaining precise detail. This 8MP camera balances wide-angle coverage and image clarity for professional video conferencing and high-end Maker projects.
Seamless Plug-and-Play Across Multiple Platforms
Equipped with a driver-free USB 2.0 (UVC) interface, this 4K camera offers true plug-and-play functionality across Windows, Linux, and Android systems without complex configuration. This compatibility ensures rapid deployment in diverse environments, from robotics development with DFRobot boards to PC-based streaming setups.
Features
- 8MP Sony IMX678 1/1.8" CMOS sensor for ultra-high-definition 4K imaging
- 95° wide FOV with 650nm IR lens for expansive, detailed scene capture
- Driver-free USB 2.0 (UVC) interface for plug-and-play on Windows, Linux, Android
- High dynamic range (HDR) and superior low-light performance
- Versatile output formats: MJPEG and YUY2 with multiple resolution/frame rate options
- Supports up to 60FPS at 1080P for silky-smooth video
Application
- AI vision recognition and edge computing projects
- HD surveillance and security monitoring systems
- Professional video conferencing and streaming
- High-end Maker education and STEM development
- Robotics and drone first-person view (FPV) applications
Specification
Basic Parameters
- Sensor: 1/1.8-Inch CMOS IMX678 8MP
- Resolution: 3840 x 2160
- Pixel Size: 2.0μm x 2.0μm
Output Format: MJPEG, YUY2
- MJPEG:
- 3840 x 2160 (4K) @30FPS
- 2592 x 1944 (5MP) @30FPS
- 2048 x 1536 @30FPS
- 1920 x 1080 (1080P) @60FPS
- 1600 x 1200 (UXGA) @30FPS
- 1280 x 960 @60FPS
- 1280 x 720 (720P) @60FPS
- 1024 x 768 @60FPS
- 800 x 600 (WVGA) @60FPS
- 640 x 480 (VGA) @30FPS
- YUY2:
- 3840 x 2160 (4K) @1FPS
- 2592 x 1944 (5MP) @1FPS
- 2048 x 1536 @1FPS
- 1920 x 1080 (1080P) @5FPS
- 1600 x 1200 (UXGA) @5FPS
- 1280 x 960 @5FPS
- 1280 x 720 (720P) @10FPS
- 1024 x 768 @10FPS
- 800 x 600 (WVGA) @20FPS
- 640 x 480 (VGA) @30FPS
- FOV (deg) @ INF: Diagonal 95°±5°, Horizontal 90°±3°, Vertical 58°±3°
- Lens: 650nm IR (EFL: 4mm, F/no: 2.8)
- Shutter Type: Electronic Rolling Shutter
- Operating Voltage: USB DC +5V Supply
- Operating Current: 170mA - 260mA ±5mA
- Operating Temperature: -15℃ ~ 60℃
- Storage Temperature: -20℃ ~ 85℃
- Humidity: 0 ~ 85%
- Supported OS: Windows, Android, Linux
- Interface: 4pin-2.0mm
- Module Size: 38mm x 38mm x 28±0.2mm
