Specification
- Pixels: 8MP
- Sensor chip: IMX678
- DSP: Auto gain/exposure/white balance
- Camera:
- CCD size: 1/1.8inch
- Aperture (F): 2.4
- Focal length (EFL): 4.2mm
- Field of View (FOV): 93°(D) 86°(H) 55°(V)
- Distortion: < -1.2%
- Focus mode: Fixed focus
- Interface type: USB2.0
- Image:
- Supported image formats: MJPG, YUY2
- Static image resolution: 3840 × 2160
- Video recording (MJPG):
- 30FPS 3840×2160
- 30FPS 2880×2160
- 30FPS 2048×1536
- 30FPS 1920×1080
- 30FPS 1600×1200
- 30FPS 1280×960
- 30FPS 1280×720
- 30FPS 1024×768
- 30FPS 800×600
- 30FPS 640×480
- Video recording (YUY2):
- 1.5FPS 3840×2160
- 1.5FPS 2880×2160
- 3.75FPS 2048×1536
- 3.75FPS 1920×1080
- 5FPS 1600×1200
- 7.5FPS 1280×960
- 10FPS 1280×720
- 10FPS 1024×768
- 20FPS 800×600
- 20FPS 640×480
- Operating voltage: 5V ± 5%
- Operating temperature: 0°C ~ 50°C
- Dimensions: 38.00 × 38.00 × 24.93 (mm)
- Supported systems: Windows, Linux, macOS
