Sensors & Peripherals
- Infrared receiver with remote control
- Digital temperature/humidity sensor interface (supports DS18B20/DHT11)
- Active buzzer
- Capacitive touch button
- 100K adjustable potentiometer
Communication & Debugging
- USB JTAG interface (programming, simulation, serial communication)
- USB SLAVE interface
- SWD 5P external debug interface
- Serial port selection interface
- Emulator function internal/external selection switch
Power Management
- 5V power input/output
- 3.3V power input/output
- Power switch
- RTC backup battery with battery included
Controls & Configuration
- Reset button
- 4 function buttons (KEY_UP with wake-up function)
- Boot mode selection interface
- Multi-function port (ADC/TPAD)
Key Features
1. Flexible Design
- Configurable resources for various applications
- Multiple I/O ports exposed (except those used by crystal oscillators)
- Onboard DAP emulator enables STM32 development via single USB cable
2. User-Friendly Design
- Clear silkscreen labeling with outlined boxes
- Prominent markings for frequently used peripherals
- Logical interface layout for convenient operation
- Optimized resource allocation
Board Dimensions
- 100mm × 60mm
